Be aware: All figures and formulation within the following sections have been created by the creator of this text.

Mathematical Instinct

The cosine similarity metric relies on the cosine operate that readers might recall from highschool math. The cosine operate reveals a repeating wavelike sample, a full cycle of which is depicted in Determine 1 under for the vary 0 <= x <= 2*pi. The Python code used to provide the determine can also be included for reference.

import numpy as np
import matplotlib.pyplot as plt

# Outline the x vary from 0 to 2*pi
x = np.linspace(0, 2 * np.pi, 500)
y = np.cos(x)

# Create the plot
plt.determine(figsize=(8, 4))
plt.plot(x, y, label='cos(x)', colour='blue')

# Add notches on the x-axis at pi/2 and three*pi/2
notch_positions = [0, np.pi/2, np.pi, 3*np.pi/2, 2*np.pi]
notch_labels = ['0', 'pi/2', 'pi', '3*pi/2', '2*pi']
plt.xticks(ticks=notch_positions, labels=notch_labels)

# Add customized horizontal gridlines solely at y = -1, 0, 1
for y_val in [-1, 0, 1]:
    plt.axhline(y=y_val, colour='grey', linestyle='--', linewidth=0.5)

# Add vertical gridlines at specified x-values
for x_val in notch_positions:
    plt.axvline(x=x_val, colour='grey', linestyle='--', linewidth=0.5)

# Customise the plot
plt.xlabel("x")
plt.ylabel("cos(x)")

# Remaining format and show
plt.tight_layout()
plt.present()

The operate parameter x denotes an angle in radians (e.g., the angle between two vectors in an embedding area), the place pi/2, pi, 3*pi/2, and a couple of*pi, are 90, 180, 270, and 360 levels, respectively.

To know why the cosine operate can function a helpful foundation for designing a vector similarity metric, discover that the fundamental cosine operate, with none practical transformations as proven in Determine 1, has maxima at x = 2*a*pi, minima at x = (2*b + 1)*pi, and roots at x = (c + 1/2)*pi for some integers a, b, and c. In different phrases, if x denotes the angle between two vectors, cos(x) returns the most important worth when the vectors level in the identical course, the smallest worth when the vectors level in reverse instructions, and nil when the vectors are orthogonal to one another.

This conduct of the cosine operate neatly captures the interaction between two key ideas in NLP: semantic overlap (conveying how a lot which means is shared between two texts) and semantic polarity (capturing the oppositeness of which means in texts). For instance, the texts “I preferred this film” and “I loved this movie” would have excessive semantic overlap (they categorical basically the identical which means regardless of utilizing completely different phrases) and low semantic polarity (they don’t categorical reverse meanings). Now, if the embedding vectors for 2 phrases occur to encode each semantic overlap and polarity, then we’d count on synonyms to have cosine similarity approaching 1, antonyms to have cosine similarity approaching -1, and unrelated phrases to have cosine similarity approaching 0.

In follow, we are going to sometimes not know the angle x straight. As an alternative, we should derive the cosine worth from the vectors themselves. Given two vectors U and V, every with n parts, the cosine of the angle between these vectors — equal to the cosine similarity metric — is computed because the dot product of the vectors divided by the product of the vector magnitudes:

The above system for the cosine of the angle between two vectors will be derived from the so-called Cosine Rule, as demonstrated within the phase between minutes 12 and 18 of this video:

A neat proof of the Cosine Rule itself is introduced on this video:

The next Python implementation of cosine similarity explicitly operationalizes the formulation introduced above, with out counting on any black-box, third-party packages:

import math

def cosine_similarity(U, V):
    if len(U) != len(V):
        increase ValueError("Vectors should be of the identical size.")

    # Compute dot product and magnitudes
    dot_product = sum(u * v for u, v in zip(U, V))
    magnitude_U = math.sqrt(sum(u ** 2 for u in U))
    magnitude_V = math.sqrt(sum(v ** 2 for v in V))

    # Zero vector dealing with to keep away from division by zero
    if magnitude_U == 0 or magnitude_V == 0:
        increase ValueError("Can not compute cosine similarity for zero-magnitude vectors.")

    return dot_product / (magnitude_U * magnitude_V)

readers can check with this article for a extra environment friendly Python implementation of the cosine distance metric (outlined as 1 minus cosine similarity) utilizing the NumPy and SciPy packages.

Lastly, it’s value evaluating the mathematical instinct of cosine similarity (or distance) with that of Euclidean distance, which measures the linear distance between two vectors and can even function a vector similarity metric. Specifically, the decrease the Euclidean distance between two vectors, the upper their semantic similarity is more likely to be. The Euclidean distance between two vectors U and V (every of size n) will be computed utilizing the next system:

Under is the corresponding Python implementation:

import math

def euclidean_distance(U, V):
    if len(U) != len(V):
        increase ValueError("Vectors should be of the identical size.")

    # Compute sum of squared variations
    sum_squared_diff = sum((u - v) ** 2 for u, v in zip(U, V))

    # Take the sq. root of the sum
    return math.sqrt(sum_squared_diff)

Discover that, because the elementwise variations within the Euclidean distance system are squared, the ensuing metric will all the time be a non-negative quantity — zero if the vectors are similar, constructive in any other case. Within the NLP context, this means that Euclidean distance is not going to mirror semantic polarity in fairly the identical method as cosine distance does. Furthermore, so long as two vectors level in the identical course, the cosine of the angle between them will stay the identical whatever the vector magnitudes. In contrast, the Euclidean distance metric is affected by variations in vector magnitude, which can result in deceptive interpretations in follow (e.g., two texts of various lengths might yield a excessive Euclidean distance regardless of being semantically comparable). As such, cosine similarity is the popular metric in lots of NLP eventualities, the place figuring out vector — or semantic — directionality is the first concern.

Idea versus Observe

In a sensible NLP situation, the interpretation of cosine similarity hinges on the extent to which the vector embedding encodes polarity in addition to semantic overlap. Within the following hands-on instance, we are going to examine the similarity between two given phrases utilizing a pretrained embedding mannequin that doesn’t encode polarity (all-MiniLM-L6-v2) and one which does (distilbert-base-uncased-finetuned-sst-2-english). We may even use extra environment friendly implementations of cosine similarity and Euclidean distance by leveraging capabilities offered by the SciPy package deal.

from scipy.spatial.distance import cosine as cosine_distance
from sentence_transformers import SentenceTransformer
from transformers import AutoTokenizer, AutoModel
import torch

# Phrases to embed
phrases = ["movie", "film", "good", "bad", "spoon", "car"]

# Load a pre-trained embedding mannequin from Hugging Face
model_1 = SentenceTransformer("sentence-transformers/all-MiniLM-L6-v2")
model_2_name = "distilbert-base-uncased-finetuned-sst-2-english"
model_2_tokenizer = AutoTokenizer.from_pretrained(model_2_name)
model_2 = AutoModel.from_pretrained(model_2_name)

# Generate embeddings for mannequin 1
embeddings_1 =  dict(zip(phrases, model_1.encode(phrases)))

# Generate embeddings for mannequin 2
inputs = model_2_tokenizer(phrases, padding=True, truncation=True, return_tensors="pt")
with torch.no_grad():
    outputs = model_2(**inputs)
    embedding_vectors_model_2 = outputs.last_hidden_state.imply(dim=1)
embeddings_2 = {phrase: vector for phrase, vector in zip(phrases, embedding_vectors_model_2)}

# Compute and print cosine similarity (1 - cosine distance) for each embedding fashions
print("Cosine similarity for embedding mannequin 1:")
print("film", "t", "movie", "t", 1 - cosine_distance(embeddings_1["movie"], embeddings_1["film"]))
print("good", "t", "unhealthy", "t", 1 - cosine_distance(embeddings_1["good"], embeddings_1["bad"]))
print("spoon", "t", "automobile", "t", 1 - cosine_distance(embeddings_1["spoon"], embeddings_1["car"]))
print()

print("Cosine similarity for embedding mannequin 2:")
print("film", "t", "movie", "t", 1 - cosine_distance(embeddings_2["movie"], embeddings_2["film"]))
print("good", "t", "unhealthy", "t", 1 - cosine_distance(embeddings_2["good"], embeddings_2["bad"]))
print("spoon", "t", "automobile", "t", 1 - cosine_distance(embeddings_2["spoon"], embeddings_2["car"]))
print()

Output:

Cosine similarity for embedding mannequin 1:
film 	 movie 	 0.8426464702276286
good 	 unhealthy 	 0.5871497042685934
spoon 	 automobile 	 0.22919675707817078

Cosine similarity for embedding mannequin 2:
film 	 movie 	 0.9638281550070811
good 	 unhealthy 	 -0.3416433451550165
spoon 	 automobile 	 0.5418748837234599

The phrases “film” and “movie”, that are sometimes used as synonyms, have cosine similarity near 1, suggesting excessive semantic overlap as anticipated. The phrases “good” and “unhealthy” are antonyms, and we see this mirrored within the detrimental cosine similarity outcome when utilizing the second embedding mannequin identified to encode semantic polarity. Lastly, the phrases “spoon” and “automobile” are semantically unrelated, and the corresponding orthogonality of their vector embeddings is indicated by their cosine similarity outcomes being nearer to zero than for “film” and “movie”.

The Wrap

The cosine similarity between two vectors relies on the cosine of the angle they type, and — not like metrics corresponding to Euclidean distance — shouldn’t be delicate to variations in vector magnitudes. In concept, cosine similarity needs to be near 1 if the vectors level in the identical course (indicating excessive similarity), near -1 if the vectors level in reverse instructions (indicating excessive dissimilarity), and near 0 if the vectors are orthogonal (indicating unrelatedness). Nevertheless, the precise interpretation of cosine similarity in a given NLP situation relies on the character of the embedding mannequin used to vectorize the textual knowledge (e.g., whether or not the embedding mannequin encodes polarity along with semantic overlap).
